SCM series S super thin mill

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1314024

• Place of Origin:

  China
•     Sell offers



  SCM series S super thin mill
  Post Date: 2006-12-22
  Expirtion Date: 30 days



  Description

  Application
  SCM series S super thin mill is widely used to produce thin powder and super thin powder, which is applicable for middle and low rigidity. It can produce powder form various non-flammable and non-explosive minerials with Mohs’ hardness below 6, such as calcite, chalk, limestone, dolomite, kaolin, bentonite, steatite, mica, magnesite, meerschaum, diatomite, barite, gypsum, alunite, graphite, fluorite, floatstone, ect.
  Working Principle:
  Mill’s motor lets rotary table circumgyrate by speed reducer, rollers are driven by the connection axes of rotary table. Big materials are broken into small ones by hammer-crusher, then put into the storage cabinet by bucket elevator, materials are equably transferred to the middle of the rotary table by vibrating feeder. Materials can be disseminated to the circle by centrifugal effect， then fall into the ball-race and grinded into powder. The materials fall into the second and third floor after the first crush. High-pressure centrifugal blower inhales outer-air which can put the grinded powder into separator. Worm wheel of separator makes bigger particle fall into grinder chamber again, and the smaller particles go into the cyclone collector and the finest powder are discharged by discharge-opening as finished product.

  SCM8021
  Diameter: 800mm
  Rollers: 21
  Ring: 2
  Feeding size: 10mm
  Size of finished product: 325-2500mesh
  Capacity: 600-4000kg/h
  Main power: 55kw
  Overall dimension: 11.9*2.7*5.8m
